Camera model card



Table

Refresh

Export

Print

Views

Compress/Expand

Hide columns

Show all columns

Save table view

Table view list

Delete table view

PDF report



The , buttons allow you to hide the toolbar.




Close



Close the Table of cameras.



Camera model card



Open the Camera model card box.



If the box is called from the Table of cameras, then the box dynamically displays the photo and the most important parameters of the camera model selected in the table (model name, camera type, key feature, sizes and resolution of the image sensor, lens focal lengths, view angles, distance of the built-in IR illumination, protection environment, supply voltage, manufacturer, vendor, cost).



See more: Photo of camera model

See also: Graphics window> Photo of camera model,  Table of camera models > Photo of camera model





Table



Refresh



As a result of choosing this item, data in the selected row will be refreshed.



Data are not refreshed automatically in program operation. Refreshing all data could take some time. To refresh only one camera parameters select any cell on the row of the camera, right-click on the cell then choose Update camera parameters in the pop-up menu.



Export



Export table of cameras to any of the following formats: *.txt, *.csv, *.htm, *.rtf, *.xls, OLEXLS, *.xlsX, *.xml. File format can be chosen in Save as dialog box appeared. If OLEXLS is selected, MS Excel opens (if installed) into which the exported table is loaded.



You can export selected fragments using pop-up menu. .



See also: PDF Report



Print



Print full table of cameras or a selected fragment of the table. Print dialog box will open in which it is possible to adjust printing options.



See also: PDF report





       Views



View - is a set, width and order of visible columns.

In the table there are more than hundred parameters by which it is possible to describe the majority of security cameras existing at the moment of VideoCAD release. In real projects there is no necessity to use all parameters. At various times different parameters sets are necessary. You can hide unnecessary columns, place the rest columns in required order and save obtained View. After that at any moment you can restore the saved View (i.e. set and order of visible columns).



The list contains Default Views. By selecting the desired View, you can immediately get a set of parameters ready for a specific task. You can edit default views and create your own views based on them.



Views of the Table of Cameras are used for selecting camera parameters for the PDF report, as well as to specify the set, column order and width for the Tables of camera parameters and the Table of cameras in the PDF report.





Compress/Expand



Compress columns so that the table is placed completely on the screen or restoring normal width of columns.



Hide columns



Hide selected columns.



Show all columns



Show all columns including hidden ones.



Save table view



Save current table view. Dialog box will open, in which it is necessary to enter view name. It may be a name of an existing View or a new name. The new name will appear in the Table view list.



Table view list



In the list there are all earlier saved views of the table. To load a view, just choose its name in the list.



Delete table view



Delete the view, the name of which is displayed in the Table view list.



PDF report



Open the PDF report panel.





See also: Table of cameras, Table interface, Pop-up menu, Camera parameters.
